10B-5 Composite Y-type sealing ring for reliable and durable use same install size with 10A-5

Großes Bild : 10B-5 Composite Y-type sealing ring for reliable and durable use same install size with 10A-5

Produktdetails:

Herkunftsort:	China
Markenname:	NBSANMINSE
Zertifizierung:	ISO9001
Modellnummer:	10B-5

Zahlung und Versand AGB:

Min Bestellmenge:	10 Stück
Preis:	Verhandlungsfähig
Verpackung Informationen:	Kasten
Lieferzeit:	5-30 Tage
Zahlungsbedingungen:	L/C, T/T
Versorgungsmaterial-Fähigkeit:	10000 Stück

Kontakt

10B-5 Composite Y-type sealing ring for reliable and durable use same install size with 10A-5

Beschreibung

Beweisdruck:	15(bar)	Betriebsmedium:	Trockene und saubere Luft
Schmierung:	Nicht erforderlich	Kissenbewegung:	20 (mm)
Betriebstemp:	-25 ~ +80(℃)	Material:	Aluminium
Hervorheben:	10B-5 Model Pneumatic Air Cylinder , 15 Bar Proof Pressure Air Cylinder , Dry and Clean Air Pneumatic Cylinder

I. Features:

Compact structure and attractive appearance.
Composite Y-type sealing ring for reliable and durable use.
Oil-impregnated bearing guide for wear resistance and stable operation.
Smooth tank body side for easy cleaning.
Integrated buffer valve and air port for more convenient installation.
Rodless design; the cylinder head and cover are solid, enhancing rigidity.
Same installation dimensions as the 10A-5 series cylinders, allowing mutual replacement

II. Model:

III. Main Technical Parameters

Cylinder Model	10B-5 (Standard)
Cylinder Bore D (mm)	Φ32	Φ40	Φ50	Φ63	Φ80	Φ100	Φ125	Φ160	Φ200
Maximum Stroke S (mm)	500	800			1000				1500
Operating Pressure Range (bar)	0.5~10
Pressure Resistance (bar)	15
Operating Speed Range (mm/sec)	50～700
Operating Temperature Range (℃)	-25 ~ +80 (under non-freezing conditions)
Operating Medium	Dry and Clean Air
Lubrication	Not Required (Lubrication Optional)
Cushioning	Adjustable Cushioning on Both Sides
Cushion Stroke (mm)	20			25				28

IV. Overall and Mounting Dimensions

SD (Basic Type)

10B-5 Composite Y-type sealing ring for reliable and durable use same install size with 10A-5 1

10B-5 Composite Y-type sealing ring for reliable and durable use same install size with 10A-5 2

10B-5 Composite Y-type sealing ring for reliable and durable use same install size with 10A-5 3

10B-5 Composite Y-type sealing ring for reliable and durable use same install size with 10A-5 4

10B-5 Composite Y-type sealing ring for reliable and durable use same install size with 10A-5 5

10B-5 Composite Y-type sealing ring for reliable and durable use same install size with 10A-5 6

10B-5 Composite Y-type sealing ring for reliable and durable use same install size with 10A-5 7
